Vacuum stuffer for straight filling, portioning and linking.

• Capacity of the filling hopper : 60/90 liters
• Maximum filling power : 2,200 kg/h
• Filling pressure up to max : 40 bar
• Capacity of the chambers : 82 g
• Number of chambers : 8
• Voltage / tension : 400 V / 50 Hz
• Total connected load max. : 4.70 Kw
• Suction power vacuum pump : 16 cbm/h
• Machine weight (net) : 400 Kg
• Portioning speed : max. 450 port/min

• Weight input can be chosen between 0.1 and 100,000 g. (from 0,0-999,9 g in 0,1 g - steps)
• Number of links from 0 -9,9 turns
• Clipping time
• Counter of quantity and pieces, pre-selection of pieces
• Preselection of pauses for portioning and linking
• Total connected load: max. 5.3 KW
• Touch operation, Motion control
• Vacuum pump
• Electronic pulse control for clipping machines
• Memory for 200 filling programs
• Speed and pause lengths are infinitely variable
